Publicado por: DANYEL CATPO el Jan 17 2023, 12:31 PM

buenas tardes compañeros:
lo primero es escoger en pandora, motorola mediatek
luego presionar eliminar frp
conectar el telefono apagado presionando el boton asiistente de google (se encuentra al lado izquierdo)
en 10 segundos fuera cuenta
Selected model: Motorola Mediatek
Operation: Erase FRP
Software version: 4.3

Host Power Off... OK
Switch virtual port to NONE... OK
Connect Type-C to HUB... OK
Host Power On... OK
Connect phone to BOX in BROM/PRELOADER Mode
Waiting for device... OK
Driver: [MediaTek Inc.,wdm_usb,MediaTek USB Port,usb2ser.sys,3.0.1504.0]
Device found at COM57 [BROM]
Open port... OK
Send start cmd... OK
Get HW code from device... 0766
Get sec config... OK [000000E5]
Active sec flags: [SBC DAA]
Get HW & SW version from device... OK
HW VER: CA00, SW VER: 0000, HW SUB CODE: 8A00
Detect chip [MT6765]
Library Version [2]
Select platform... OK
Init BROM... OK
Force Charge... OK
Disable WatchDog Timer... OK
Force switch to BROM... OK
Host Power Off... OK
Switch virtual port to USB... OK
Connect Type-C to BOX... OK
Host Power On... OK
Waiting for device... OK
Read usbhost speed... HIGH
Read Device Descriptor...
Get VID/PID...0E8D/0003
Send start cmd... OK
Get HW code from device... 0766
Get HW & SW version from device... OK
HW VER: CA00, SW VER: 0000, HW SUB CODE: 8A00
Detect chip [MT6765]
Get sec config... OK [000000E5]
Active sec flags: [SBC DAA]
Advanced Bypass Security... OK
Switch virtual port to NONE... OK
Connect Type-C to HUB... OK
Waiting for device... OK
Driver: [MediaTek Inc.,wdm_usb,MediaTek USB Port,usb2ser.sys,3.0.1504.0]
Device found at COM57 [BROM]
Open port... OK
Send start cmd... OK
Get HW code from device... 0766
Get sec config... OK [000000E0]
Active sec flags: []
Get HW & SW version from device... OK
HW VER: CA00, SW VER: 0000, HW SUB CODE: 8A00
Detect chip [MT6765]
Library Version [2]
Select platform... OK
Init BROM... OK
Force Charge... OK
Disable WatchDog Timer... OK
Reopen port for libver2... OK
Get ME ID... OK
ME_ID = 0x978F21E4, 0x6D9D7DDA, 0x0C26BAB9, 0xB654BA0C
Get Chip ID... [MT6765]
Get SOC ID... [0971B9D48F1EBB111DC00773B0F15AE8D29DAF153B88F6897133B742ECEBD74A]
Get sec config... OK [000000E0]
Load DownloadAgent... OK
Search DA... OK [7]
Send preloader... OK
Start preloader... OK
Checking preloader answer... OK
Send bootloader... OK
Start bootloader... OK
Wait for answer from bootloader... OK
Send SYNC signal... OK
Setup device enviroment... OK
Setup device parametres... OK
Receive DA SYNC signal... OK
Set DA parametres... OK
Get device connection agent... [BROM]
Get device info... OK
EMMC_ID: 0x1501003458364B4D42034473F3004827
Load EMI from phone... OK
Parse EMI config... OK
Init EXT RAM... OK
Send 2nd DA... OK
Get device info... OK
EMMC INFO:
EMMC_CNAME: 4X6KMB
EMMC_ID : 0x1501003458364B4D42034473F3004827
EMMC_BOOT1: 0x0000400000 (4.00Mb)
EMMC_BOOT2: 0x0000400000 (4.00Mb)
EMMC_RPMB : 0x0000400000 (4.00Mb)
EMMC_USER : 0x0747C00000 (29.12Gb)
RAM INFO:
INT_SRAM: 0x000003A000 (232.00Kb)
EXT_RAM : 0x0080000000 (2.00Gb)
Checking USB status... USB_HIGH_SPEED
Read partitions info from phone... OK
Checking A/B state... OK [B]
Read product info... OK
Product Brand : motorola
Product Manufacturer : motorola
Product Model : moto e(7)
Product Name : malta
Product Device : malta
Product Board : malta
Board Platform : MT6765
Build ID : QOFS30.569-83-11
Build Date : Tue Nov 1 23:36:57 CST 2022
Display ID : QOFS30.569-83-11
Security Patch : 2022-11-05
Version SDK : 29
Version Release : 10
Version Codename : REL
Firmware Version : 45005
Read partition "frp"... OK
Backup saved to HYPERLINK C:/Program%20Files%20(x86)/Z3X/Pandora/Backup/MTK/Motorola_MT6765/FRP_BACKUP_(2023-1-17_11-26-22)/"directory
Writting FRP data... OK
Erase FRP done!
